Remote RMX-3200 Version 5.2x Configuration Guide
Configuring a Wireless Network with Remote RMX-3200: Configuring the Wireless Modem
11-6
Configuring the Wireless Modem
Important: If you use the initsetup wizard to provision the wireless modem, then this
procedure is unnecessary.

Note: This procedure configures a UMTS wireless modem. The same procedure can
be used to configure an EvDO wireless modem with the addition of the
activation step (see note below).
To configure the UMTS wireless modem settings:
1. Configure description
UMTS wireless modem for controller serial wan/1:
config controller serial wan/1 description UMTS wireless modem
2. Configure the wan/1 serial controller’s connection string as @gprsChat.txt:
config controller serial wan/1 connect string @gprsChat.txt

Note: The user must upload the chat file to directory /config/chat on Remote
RMX-3200 before it is entered as the connect string in the CLI. This is not
required if using the initsetup wizard.
3. Assign controller
serial wan/1 as a resource:
config controller serial wan/1 assign

Note: For an EvDO modem only, activate the network name:
diag controller serial wan/1 activate <network name>
In this scenario, you will:
 Configure a description for the wireless modem
 Configure a connection string for the wireless modem
 Assign the wireless modem as a resource
 Configure the PPP encapsulation settings
 Configure the UMTS wireless modem interface
 Activate an EvDO wireless modem
