Remote RMX-3200 Version 5.2x Configuration Guide
Remote RMX-3200 Product Overview: Remote RMX-3200 Hardware Configuration
1-5
WAN Peripherals
 RMX-WWAN is a single WAN card that supports either an EvDO or UMTS phone
module.
 RMX-WTE is a single WAN card that supports either Dual port or Drop and
Continue (DAC) in either T1 or E1 mode.
Figure 1-3 shows an example of the
Remote RMX-3200 with a WTE peripheral.
For details on Remote RMX-3200 WAN peripherals and port assignments, see
Appendix B : WAN Port Availability.
Figure 1-3 Remote RMX-3200 With WTE Peripheral
For information on the Remote configurations, see Table 1-1 on page 1-10.
WTE Peripheral
