Remote RMX-3200 Version 5.2x Configuration Guide
Configuring the Peripheral Management Subsystem: Configuring SiteBus Devices for an Expansion
Peripheral
25-21
5. Configure the device with name temp1:
config sitebus temp1
Note: Each SiteBus device should be assigned a unique name in order to track
and store its reported values in the measurement table.
6. Configure device
temp1 with hexadecimal ID 28004564AE05A5:
config sitebus temp1 id 28004564AE05A5
7. Assign device type sbTemp to device temp1:
config sitebus temp1 type sbTemp
Note: The device type determines how data from the device will be interpreted
and what points will be created for the device. The only SiteBus device
type supported for Remote RMX-3200 version 5.2x is
sbTemp, which
includes points for Celsius and Fahrenheit temperatures. The device in
this example would have two logical points:
sitebus
temp1/temperatureC and sitebus temp1/temperatureF.
8. Add description Temperature Sensor 1 to device temp1:
config sitebus temp1 description Temperature Sensor 1
9. (optional) Verify that the SiteBus device has been configured properly:
show sitebus
The display will look similar to the following:
10. Save the configuration.
Note: For information on configuring a measurement-table entry for a SiteBus
device, see section
Configuring a Measurement Table Entry for a
Temperature Sensor and its subsection Sample Configuration for SiteBus
Temperature Sensor.
(Dub)>show
(Dub) show>sitebus
ID Periph:Bus State Managed Name
------------------------------------------------------------------------------
28004564AE05A5 1:1 Managed temp1
Name ID State Type Description
-----------------------------------------------------------------------------
temp1 28004564AE05A5 Online sbTemp Temperature Sensor 1
(Dub) show>
