Using PageScope Web Connection
7
IC-402 7-55
Item Description
No. Displays the LDAP server number.
LDAP Server Name Enter the LDAP server name.
Server Address Enter the LDAP server address (syntax: “***.***.***.***” or
FQDN where the input range of *** is 0 to 255). Symbols “-”
and “.” can be used.
Port No. Enter the port number used to communicate with the LDAP
server (input range: 1 to 65535).
Enable SSL/Port No. (SSL) Specify whether to perform communications with the LDAP
server using SSL. Also, enter the port number to be used
(input range: 1 to 65535).
Search Base Enter the search start point of the LDAP search (up to 255
characters).
Timeout Enter the LDAP search timeout (input range: 5 to 300
seconds).
Max Search Results Enter the maximum number of hits to be received as the LDAP
search result (input range: 5 to 1000).
Authentication Method Set the LDAP authentication method.
Login Name Enter the login name if authentication is not set to
“anonymous” (up to 255 characters).
Password Enter the password if authentication is not set to
“anonymous” (up to 128 characters).
Domain Name Enter the domain name if authentication is set to “GSS-
SPNEGO” (up to 64 characters).
Select Server Authentication
Method
Select the LDAP server authentication method.
Use Referral Specify whether to use the referral setting. When referral is
used, the search base that was specified in LDAP Sever Set-
ting searches the top and bottom levels as the starting point.
[Check Connection] button Click to check the connection to the LDAP server using the
specified settings.
To Next Page
