Repair information 4-55
5026
Installation note: Gently pull the cartridge guide, then use a long-nosed pliers to hold the cartridge
guide wheel in place when installing a new cartridge wheel.
Installation note: Inspect carefully if the cartridge guide wheel is seated properly on the cartridge
guide before reinstalling the screw on the cartridge guide.
2. For black:
a. Remove the screw (C) from the lower-most cartridge guide.
To Next Page
