Repair information 4-73

5026

Go Back

Installation notes:

• When installing, make sure the top half (E) of the spring is under the straight spring (F). This is typical for

both types of springs. Also make sure the bottom half (D,G) of both springs are compressed and locked by

the appropriate locking tabs (H, I).
