Repair information 4-183

5026

Go Back

5. Install the waste toner HV contact assembly into place. Route the toner level sensor cables (E) through the

holes in the waste toner HV contact assembly while positioning the assembly. Make sure the aligner shaft

worm gear is aligned as shown.

Ribs aligned Rib
