Connector locations 5-7

5026

Go Back

JMIRR1

Mirror motor

1MM_REFR

2 TG_MM_LOCK

3 TG_MM_START

4Ground

5 +25VC

JOPP1

Operator panel (12C)

1I2C_DATA

2 V12_PANEL+5V

3 I2C_CLK

4Ground

5 TG_OP_IRQ-

6 +3.3 V dc

7Ground

JOPT1

Option port

1 +25VE 2Ground

3 S_OPT_RXR 4Ground

5 S_INPUT_FDT 6 VS24_OPT_5V

7Ground 8 S_OPT_TXR

System board listing (continued)

See “System board diagram” on page 5-2.

Connector Pin # Signal Pin # Signal
