5-8 Service Manual

5026

Go Back

JPH1

Printhead

1 VDO_SYNC_C

2 VDO_PHR_OK

3 VDO_SYNC_B

4 VDO_LENA

5 TG_VDO_SHADE_D

6 VS12_+3.3VPH

7 TG_VDO_SHADE_C

8 VS12_JPH1

9 TG_VDO_SHADE_B

10 VS12_JPH1

11 TG_VDO_SHADE_A

12 Ground

13 D_VDO_D2+

14 D_VDO_D2-

15 Ground

16 D_VDO_D+

17 D_VDO_D-

18 Ground

19 D_VDO_C2+

20 D_VDO_C2-

21 Ground

22 D_VDO_C+

23 D_VDO_C-

24 Ground

25 D_VDO_B2+

26 D_VDO_B3-

27 Ground

28 D_VDO_B+

29 D_VDO_B-

30 Ground

31 D_VDO_A2+

32 D_VDO_A2-

33 Ground

34 D_VDO_A+

System board listing (continued)

See “System board diagram” on page 5-2.

Connector Pin # Signal Pin # Signal
