Issue 2.2
Feature Description and Operation Manual
198
13.10 DSS/DLS Consoles
Description
The Attendants and other DKT stations may be equipped with DSS/DLS Consoles that provide
an additional 48 Flexible buttons each. The buttons function as any other Flexible button on
the associated DKT. Up to three (3) Consoles may be equipped for each station. Each
console requires a separate connection to the ipLDK and reduces the available stations by one
for each console.
The buttons on the console are fully programmable and provide the user with one-button
access to the assigned CO line, station or feature for more convenient operation. Each button
has associated LEDs to display status for the CO line, station or feature. One of three
templates or Maps for the Flexible buttons is assigned for the Console providing basic
configuration of the buttons. The buttons can then be individually assigned a desired function
other then the template function.
Consideration
There is no limit to the number of DSS/DLS consoles in the system other then the
maximum number of DTK stations.
The default templates (maps) available for the Console are shown in the chart below.
Map 1 Flex 1 - Intrusion
Flex 2 - All Call Page
Flex 3 - Call Park 01
Flex 4 - Station Group 1
Flex 5 - Camp-on
Flex 6 - Internal All Call Page
Flex 7 - Call Park 02
Flex 8 - Station Group 2
Flex 9 - Group Call Pick-up
Flex 10 - External All Call Page
Flex 11 - Call Park 03
Flex 12 - Station Group 3
Flexible buttons 13 to 48 - Stations 100-135
Map 2 Flexible buttons 1 to 12 – Stations 136 to 147
Map 3
No default assignments
Reference
A. Flexible Buttons
Admin Programming
Station ID Assignment (PGM 110, Flexible button 1),
Assigns the type of terminal
DSS/DLS ID Assignment (PGM 110, Flexible button 2)
Assigns a Console and a Console button template to a Station
