LG-Ericsson ipldk-60 - Flexible Button Assignment (PGM 115)

ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
36
3.2.6 Flexible Button Assignment (PGM 115)
PGM 115 defines the function of the DKT Flexible buttons.
Procedure:
1. Press the [TRANS/PGM] button.
2. Dial 115.
3. Enter the appropriate Station Range.
4. Dial 1 to assign one of the 1
st
24 buttons and 2 for the 2
nd
24 buttons.
5. Select the desired Flexible button.
6. Enter the appropriate Type and Range.
7. Press the [Hold/Save] button.
PGM
115
Flex
Btn
Description Default Value
Flex Button
Assignment
All Each Flexible button of a DKT and Console can be assigned a function (Type) and
value (Range). The Type and Range are shown in the Button Assignment Table
below.
See Button
Default Table
Type = 01 ~ 11
Range = see Button
Assignment Table
Button Assignment Table
Function.
No. Button Type
Range Description
1 Undefined Undefined, User programmable
2 {CO line xx} 01 – 36 CO line
3 {CO line Group xx} 01 – 24 CO line Group
4 {LOOP}
