LG-Ericsson ipldk-60 - Incoming CLID Destination Table (PGM 237)

ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
173
3.9.13 Incoming CLID Destination Table (PGM 237)
PGM 237 defines the destination for DID calls when the CLI matches one of up to 100 CLI entries.
Procedure:
1. Press the [TRANS PGM] button.
2. Dial 237.
3. Enter the ICLID Table index (001 ~ 100)
4. Select the desired Flexible button.
5. Enter the appropriate value.
6. Press the [Hold/Save] button.
PGM
237
Flex
Btn
Description Default Values
Incoming CLI
Number
1 This parameter assigns a CLI that, if matched with the CLI on an incoming DID CO
line call, routes the call to the destination specified under Flexible button 2.
Not assigned Up to 20 digits
Conversion Table
Index
2 This parameter defines the Flexible DID Conversion Table index (PGM231) for the
destination for a call when the CLI on an incoming DID call matches the CLI defined
under Flexible button 1.
Not assigned 000 ~ 999, Flexible
DID Conversion
Table index
