3.5.23 Chime Bell Attributes (PGM 184)
PGM 184 defines the Chime Bell station pairs and the Chime Bell signal characteristics.
Procedure:
1. Press the [TRANS PGM] button.
2. Dial 184.
3. Select the desired Flexible button.
4. Enter the appropriate value.
5. Press the [Hold/Save] button.
PGM
184
Flex
Btn
Description Default Values
Chime Bell
Station Pair
1 This parameter defines the Chime Bell pair (01 ~ 14); the first station activates the
Chime Bell and the second station receives the Chime Bell signal.
Not assigned 01 ~ 14 + station pair
Chime Bell Relay 2 This parameter assigns a Chime Bell pair (01 ~ 14) to activate an External Control
Relay as a Loud Bell contact.
Not assigned 01 ~ 14 + External
Control Relay, 0 ~ 2
Bell Timer 3 This parameter determines the duration of the Chime Bell signal at the receiving
station. The same timer is used for all 14 Chime Bell pairs
02 seconds 01 ~ 20 in 1 second
increments
Bell Frequency 4 This parameter defines two frequency components that make up the Chime Bell
signal. The same Chime Bell frequencies are used for all 14 Chime Bell pairs. Use
Flexible button 1 for T1 and Flexible button 2 to set T2.
T1 0770
T2 0000
T1 = 4 digits in Hz
T2 = 4 digits in Hz
