LG-Ericsson ipldk-60 - Board Assignment (PGM 101)

ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
8
3.1.2 Board Assignment (PGM 101)
PGM 101 configures the type of board installed in a slot. This program is only required when a board is installed in an operational system.
Procedure:
1. Press the [TRANS/PGM] button.
2. Dial 101.
3. Dial desired slot number, see Slot Number chart below.
4. Select Flexible button 1.
5. Enter the appropriate value.
6. Press the [Hold/Save] button.
PGM
101
Flex
Btn
Description Default Values
Board Id 1 This parameter defines the type or function of the board installed. The Main and
Expansion boards may actually have two sub-boards, a station, and CO board, each
with a different slot number.
See Board Id Chart
below
Devices for
Board
2 This parameter displays the number of ports or channels available with the board
and is not adjustable.
Board Identification Code
Board Type Station ID. Code CO Line ID Code Misc. ID Code
CHB-308 17, DSIB8 33
CSB316 13, SLIB16 33
CKB316* 22, DTIB16 33
E1HB8 17, DSIB8 40
