LG-Ericsson ipldk-60 - 3 Admin Programming Procedures; Basic Set-Up (PGM 100 - 109); Location (PGM 100)

ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
5
3 ADMIN PROGRAMMING PROCEDURES
3.1 Basic Set-up (PGM 100 – 109)
3.1.1 Location (PGM 100)
PGM 100 defines the country or region for the installation and a Site Name.
Procedure:
1. Press the [TRANS/PGM] button.
2. Dial 100.
3. Select the desired Flexible button from the chart below.
4. Enter the appropriate value.
5. Press the [Hold/Save] button.
If the Nation Code is changed, it is necessary to set the database to the default values. To default the system,
1. Remove the Basic KSU cover.
2. Set DIP-switch 1-position 4 to the ‘On’ position.
3. Press the Reset button.
4. After the system has reset, set DIP-switch 1-position 4 to the ‘Off’ position.
5. Re-install the Basic KSU cover.
