3.1.8 System IP Setup (PGM 108)
PGM 108 configures the IP address parameters for the system LAN port.
Procedure:
1. Press the [TRANS/PGM] button.
2. Dial 108.
3. Select the desired Flexible button from the chart below.
4. Enter the appropriate value.
5. Press the [Hold/Save] button.
PGM
108
Flex
Btn
Description Default Values
IP Name 1 This parameter assigns a Name, up to 15 characters, associated with the system’s
LAN port.
Not assigned 15 characters
ipLDK Server IP
address
2 This parameter defines the IP address for the system’s LAN port. This address is
assigned to allow LAN access to the system database and maintenance functions.
192.168.1.1 IPv4 address
CLI IP address 3 not used
Gateway Address 4 This parameter defines the IP address of the gateway serving the system LAN port. 0.0.0.0 IPv4 address
Subnet Mask 5 This parameter defines the Subnet mask for the system LAN interface. 255.255.255.0 IPv4 Subnet mask
Point-to Point
Protocol
6 This parameter enables use of Point to Point protocol with the optional Modem unit
or an ISDN PRI Line.
0 (Off) 0 = Off
1 = On
Dial Pad Character Map
1 – 10
‘.’ – 13
2 – 20
A – 21
3 – 30
D – 31
