Issue 2.2
Feature Description and Operation Manual
256
17.3.1 Configuration Text File
Description
A text file, containing the basic configuration of a system, is available in real-time when using
PC Admin. The file is generated by the system under the Supplementary Service Program
group by selecting ‘Save’ system information. The file can then be named, saved and
reviewed. Information contained in the Configuration file includes:
Number of stations total and in use;
Physical port for each station;
Extension types (digital, analog and IP);
Number of CO lines;
Physical port for each CO line;
Trunk types (R2-MFC, Analog, IP and others);
Applications in-use and available.
Consideration
Database access is allowed to only a single user, DKT or PC Admin at a time;
simultaneous database access is not allowed.
This feature is not available when using Digital Keyset Admin.
Reference
A. PC Admin, On-Line
Admin Program
IP Setting, Server IP Address (PGM 108, Flexible button 2)
Assigns an IP address to the system LAN port
IP Setting, Gateway IP Address (PGM 108, Flexible button 4)
Assigns an IP address for the system LAN port gateway
IP Setting, Subnet Mask (PGM 108, Flexible 5)
Assigns the subnet mask to the system LAN port
PPP Usage (PGM 108, Flexible button 8)
When required, configures the PPP connection
RS-232C Port Settings (PGM 174)
Configures the RS-232 serial port and the Modem Unit
Modem Assignment (PGM 170)
Assigns the Associate CO line or station for the Modem Unit
