ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
129
3.7 Station Group (PGM 190 – PGM 191)
3.7.1 Station Group Assignments (PGM 190)
PGM 190 assigns the type of Station group, member stations, and the Pick-up attribute for each Station Group.
Procedure:
1. Press the [TRANS PGM] button.
2. Dial 190.
3. Select the desired Flexible button.
4. Enter the appropriate value.
5. Press the [Hold/Save] button.
PGM
190
Flex
Btn
Description Default Values
Group Type 1 This parameter determines the type of Station or Hunt Group. Not assigned 0 = Not Assigned
1 = Circular
2 = Terminal
3 = UCD
4 = Ring
5 = VM
6 = Pick up
7 = Networking VM
Pick up Attribute 2 When enabled (On), stations in the group can Pick-up calls for other stations in the
group. The Pick-up attribute has no affect on Station Pick-up groups.
0 (Off) 0 = Off
1 = On
Member 3 This parameter assigns stations to the group. Stations are assigned individually by None assigned Flexible button 1 ~ 24
