3.1.3 Logical Slot Assignment (PGM 103)
PGM 103 defines the logical order and therefore logical port numbers associated with a slot. To support IP Phones assign slot ‘99’ (Virtual VMIB) as
a Station board in the desired logical order. The system will allocate station numbers to the system using the number of IP Phones entered in PGM
381.
Procedure:
1. Press the [TRANS/PGM] button.
2. Dial 103.
3. Select the desired Flexible button.
4. Enter the appropriate slot number.
5. Press the [Hold/Save] button.
PGM 103 Flex Btn Description Default Values
CO line Board 1 This parameter defines the logical order of the CO line slots. 05 ~ 08
Station Board 2 This parameter defines the logical order of the Station slots 01 ~ 04 & 99
Voice Mail
Interface Board
3 This parameter defines the logical slot number for the Voice Mail/AA boards 09
