LG-Ericsson ipldk-60 - SIP Attributes I (PGM 500, PC Admin Only)

ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
193
3.12.3 SIP Attributes I (PGM 500, PC Admin only)
PGM 500 is one of two PGMs used to configure SIP operation, see also PGM 501.
Procedure:
1. PC Admin only.
PGM
500
Flex
Btn
Description Default Values
Proxy Server
Address
This parameter defines the IP address or URI for the SIP proxy server. Not assigned Max 32 digits
character string (e.g.
abcd@efg), see Dial
Pad Character chart
Proxy Server Port This parameter defines the port used for SIP messages to/from the SIP Proxy
server.
5060 0000 ~ 9999
Proxy
Registration
Timer
This parameter defines the valid registration interval the system will request when
registering with a SIP Call server.
3600 seconds 0 ~ 65535 (sec)
Use Outbound
Proxy
When enabled (On), the system sends SIP signaling messages to the SIP Proxy
otherwise messages are sent to the Call server.
On Off
On
Primary DNS
Address
This parameter defines the primary Domain Name Server the ipLDK will use to
convert a URI to an IP address.
Not assigned IPv4 address
Secondary DNS
Address
This parameter defines the secondary Domain Name Server the ipLDK will use to
convert a URI to an IP address if the primary DNS does not respond.
Not assigned IPv4 address
Domain This parameter defines the domain (name or IP address) used by the system in To:
and From: SIP messages when a separate SIP User id is not defined. See also
PGM 111 Flexible button 23 and PGM 501.
Not assigned Value : Max 32 digits
character string (e.g.
domain.name.com)
Connection Mode This parameter defines the transport mode for SIP signaling messages, Transport UDP UDP
