ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
73
3.3.7 CO Line Attributes III (PGM 146)
Program 146 is one of three PGMs that assign general attributes to the CO line range. Also, see PGMs 141 and 142.
Procedure:
1. Press the [TRANS/PGM] button.
2. Dial 146.
3. Enter the appropriate CO line Range.
4. Select the desired Flexible button.
5. Enter the appropriate value.
6. Press the [Hold/Save] button.
PGM
146
Flex
Btn
Description Default Values
Incoming Prefix
Code Insertion
1 When enabled (On), the My Area and Prefix codes (PGM 200, Flexible buttons 9
&10) are inserted in front of received CLI for incoming calls
0 (Off) 0 = Off
1 = On
Outgoing Prefix
Code Insertion
2 When enabled (On), the My Area and Prefix codes (PGM 200 Flexible buttons 9 &
10) are inserted in front of the CLI for outgoing calls.
0 (Off) 0 = Off
1 = On
ISDN Line Type 3 This parameter determines the codec used by the ISDN or IP line. The codec can
be PCM u-Law (NA standard) or A-Law (EU standard).
1 (u-Law) 0 = A-Law
1 =
-Law
Calling Sub-
address
4 When enabled (On), the bit for the calling party sub-address in the ISDN Setup
message is set for outgoing calls. (Intended for Norway only)
0 (Off) 0 = Off
1 = On
DID Digit Receive
No.
5 This parameter defines the number of DID digits the system expects to receive after
digit removal (PGM 143, Flexible button 5).
3 2 - 4
DID Digit Mask 6 This parameter defines the DID digit conversion process (Digit Mask) for Type ‘0’
and ‘2’ DID Conversion (PGM 143, Flexible button 4).
‘# * * *’ 2 to 4 digits
0 ~ 9, * and #
# = delete digit
To Next Page
