ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
9
Board Type Station ID. Code CO Line ID Code Misc. ID Code
T1/PRI
PRIH8 17, DSIB8 31
T1HB8 17, DSIB8 50
SLIB8 14
VMIU 64
AAFU 65
VOIB 41
* For use only as Expansion board in second cabinet (EKSU)
Slot Number Chart
Slot Slot Location Type of Board Supported
01 BKSU Main board station slot Hybrid
02 BKSU Expansion board station slot Hybrid,SLIB8,SLIB16
EKSU w/EMU Main board station slot Hybrid 03
EKSU w/EMU2 Main board station slot DTIB16
EKSU w/EMU Expansion board station slot Hybrid,SLIB8,SLIB16 04
EKSU w/EMU2 Expansion board station slot Hybrid, DTIB16
05 BKSU Main board CO line slot Analog CO
06 BKSU Expansion board CO line slot Analog CO, E1, T1 or PRI
07 EKSU Main board CO line slot Analog CO
08 EKSU Expansion board CO line slot Analog CO
09 VMIB or AAFB VMIB or AAFU
10 VOIB VOIB
