Issue 2.2
Feature Description and Operation Manual
245
PSTN, use to place a call that terminates to a public network
Net, use to access internal resources (stations, paging, etc.) of a networked system
12. Enter Numbering Plan code digits, up to 16.
13. Enter Network CO Group to use for the Numbering Plan Code
14. Repeat for each Network Numbering Plan code.
Each Numbering Plan code is a series of up to 16 digits. If the DID number or station user
dialed number matches a Numbering Plan Code, the call is routed using the instructions for the
code. The code can be a Station number sequence, CO Transit-out code or a Network VM
Group code.
The Network Numbering Plan code for local station to station calls is the first digit of the Station
Numbering Plan (PGM 105) followed by ‘#’ to indicate local and ‘*’ as wild card digits, e.g., 1#**
for the remaining station number digits. The Numbering Plan code for networked station to
station calls is the first digit of the Station Numbering Plan of the network system followed by ‘*’
as a wild card for the remaining station number digits, e.g., 2**, 3**, etc. A Network
Numbering Plan code is required for each networked system to allow station to station and DID
call routing over the network.
Example customer requirements:
Three sites are to be linked in a network using ISDN PRI lines
System A is HQ with station numbers 100 to 133
System B is Branch 1 with station numbers 200 to 214
System C is Branch 2 with station numbers 300 to 328
Incoming DID numbers are 555-7200 to 555-7450 at HQ only
HQ has a 12 channel partial PRI for DID lines, 3 analog CO lines (one is a Private line)
and 8 IP channels for networking
Branch 1 has 4 IP channels for networking and 3 analog CO lines
Branch 2 has 8 IP channels for networking and 4 analog CO lines, one is a Private line
For the main number, 555-7200, a CCR announcement is desired as an Auto Attendant
Branch 1 and 2 can access local lines in HQ using dial code ‘4 3’, CO Transit-out
The HQ system will provide CAS and Centralized VM
Station Numbering Plan, PGM 105
HQ station range 100 ~ 147
Branch 1 station range 200 ~ 247
Branch 2 station range 300 ~ 347
CO line Type and Attributes, PGM 140, 141, 143 and 146
HQ CO line range 01 ~ 03 analog CO lines
Type: Normal, 01 & 02 DISA Service On for remote VM access
CO line 01 & 02 CO Group 01
CO line 03 CO Group 00 Private line
CO line range 4 ~ 15 PRI lines for incoming DID and outgoing calls
Type: DID/MSN
CO line Group 02
DID Conversion Type 2, remove 4 digits, Digit Mask = ‘* * *’
Flexible DID Table
Index 200 route to VMIB 001 for Auto Attendant CCR
