ipLDK-60 Issue 2.0
Admin Programming Manual July, 2010
66
PGM
142
Flex
Btn
Description Default Values
Open Loop
Detect Timer
13 Common analog CO lines use a short ‘Open Loop’ signal as disconnect. This
parameter defines the minimum duration of the expected Open Loop disconnect
signal.
03 (300 milli-
seconds)
00 – 20 in 100-milli-
second increments
Line Length 14 In certain regions (SAF), the CO line length to a system may vary greatly. In this
case, the length can be assigned as Short or Long for each CO line.
0 (Short) 0 = Short
1 = Long
DISA Answer
Timer
15 When a call is received on a CO line with DISA service, the system will answer the
call when the DISA Answer Timer expires.
2 (2 seconds) 1 – 9 in 1-second
increments
DISA Delay
Timer
16 Once answered, the system attaches a DTMF receiver to the DISA call to receive
caller-dialed digits. This timer introduces a delay before attaching the DTMF
receiver to the CO line.
1 (1 second) 1 – 9 in 1-second
increments
SMDR Print 17 When enabled (On), calls on the CO line(s) will be included in the SMDR outputs. 1 (Yes) 0 = No
1 = Yes
Busy/Error CPT
Detect
18 If this parameter is enabled (On), calls on a CO line connected to another CO line
are dropped and the CO lines returned to idle if busy or error tone is detected.
1 (On) 0 = Off
1 = On
LD Delay Count 19 In some cases, the PSTN may require a delay when setting up LD calls. This
parameter sets the duration the system will delay dialing after an LD code is sent to
the PSTN.
0 (no delay) 0 – 5 in 1-second
increments
Dial Pad Character Chart
1 – 10
‘.’ – 13
Q – 11
Z – 12
2 – 20
A – 21
B – 22
C – 23
3 – 30
D – 31
E – 32
F – 33
4 – 40 5 – 50 6 – 60
