U28
BASIC SYSTEM
Refrigerant Lines Removal Note
Nut joint type
1. Loosen the nut using two spanners, then remove the cooler pipe or hose.
Block joint type
1. Disconnect the block joint type pipes by grasping female side of the block with pliers or similar tool and holding
firmly, then remove the connection bolt or nut.
Spring-lock coupling type
1. Set the SST.
2. While looking through the inspection hole of the
SST, insert the protruding part of the SST until it
makes contact with the cage section.
3. Use the SST to disconnect the male pipe or hose
from the female by pulling the male pipe or hose.
Note
• The male pipe or hose can be disconnected
easily from the female pipe by pulling from
the male pipe or hose while maintaining the
pressure of the protruding part of the SST.
A6E8516W023
A6E8516W014
A6E8516W015
A6E8516W016
