Mazda 6 2002 - Page 1174

TD6
TECHNICAL DATA
End Of Sie
FRONT AND REAR AXLE
A6E931001018W01
End Of Sie
STEERING SYSTEM
A6E931001034W01
* : When reservoir tank is at maximum volume
End Of Sie
Input/turbine speed sensor
(ohm)
ATF temperature: 40160 °C {40
320 °F}
250600
Vehicle speedometer sensor (VSS)
(V)
4.55.5
Solenoid valve (ohm)
ATF
temperature:
40150 °C
{40302 °F}
Shift solenoid A 1.04.2
Shift solenoid B 1.04.2
Shift solenoid C 1.04.2
Shift solenoid D 10.926.2
Shift solenoid E 10.926.2
Pressure control 2.47.3
Item Specification
Item
Specification
ATX MTX
FRONT AXLE
Maximum wheel bearing play (mm {in}) 0.05 {0.002}
REAR AXLE
Maximum wheel bearing play (mm {in}) 0.05 {0.002}
DRIVE SHAFT
Shaft length (Air in
boot at atmospheric
pressure)
(mm {in})
Left side 674.5684.5 {26.5626.94}
677.7687.7 {26.6727.07} (L8, LF),
676.6686.6 {26.6427.03} (L3)
Right side 631.2641.2 {24.8625.24} 628.6638.6 {24.7525.14}
Item Specification
ENGINE SPEED SENSING POWER STEERING
Steering wheel
Play (mm {in}) 030 {01.18}
Effort (N·m {kgf·cm, in·lbf}) 7.8 {80, 58} max.
Steering shaft Length (mm {in}) 211.6 {8.3}
Steering gear
Tie-rod end
Rotation torque (N·m {kgf·cm, in·lbf}) 0.42.7 {3.527.5, 3.123.8}
[Pull scale reading] (N {kgf, lbf}) 3.425.5 {0.352.60, 0.85.7}
Tie rod
Swinging torque (N·m {kgf·cm, in·lbf}) 0.14.0 {140.7, 0.935.3}
[Pull scale reading] (N {kgf, lbf}) 0.624.5 {0.062.49 0.25.5}
Steering
rack
Runout
Large diameter
portion
0.15 mm {0.006 in} max.
(mm {in}) Small diameter
portion
0.20 mm {0.008 in} max.
Power steering oil
pump
Oil pump fluid pressure
(MPa {kgf·cm
2
, psi})
10.8011.29 {110.2115.2, 15671637}
Gear housing fluid pressure
(MPa {kgf·cm
2
, psi})
10.8011.29 {110.2115.2, 15671637}
Power steering
system
Fluid
Type
ATF M-
III
or equivalent (e.g. Dexron
®
II
)
Capacity*
(Approximate
quantity)
(L {US qt, Imp qt})
0.80 {0.85, 0.70} (MTX)
0.87 {0.92, 0.77} (ATX)
