TECHNICAL DATA
TD5
TD
CLUTCH
A6E931001024W01
End Of Sie
MANUAL TRANSAXLE
A6E931001024W02
End Of Sie
AUTOMATIC TRANSAXLE
A6E931001024W03
Item Specification
Clutch pedal
Height (with carpet) mm {in}
L.H.D.: 226222 {8.508.74}
R.H.D.: 229235 {9.029.25}
Free play
Pedal free play mm {in} 1.03.0 {0.040.11}
Push rod free play at
clutch pedal
mm {in}
0.10.5 {0.0040.02}
(Reference value)
Disengagement
point
Disengagement stroke mm {in}
20 {0.79}
(Reference value)
Pedal stroke mm {in}
130.7 {5.15}
(Reference value)
Clutch cover
Diaphragm
spring fingers
Depth mm {in} 0.6 {0.024}
Misalignment mm {in} 0.6 {0.024}
Maximum clearance of flatness of the
pressure plate
mm {in} 0.5 {0.020}
Clutch disc
Minimum thickness mm {in} 0.3 {0.012}
Run out limit mm {in} 0.7 {0.028}
Flywheel Run out limit mm {in} 0.1 {0.004}
Item Specification
Manual transaxle type G35M-R
Transaxle oil
Grade API service GL-4 or GL-5
Viscosity
All-season SAE 75W-90
Above 10 °C {50 °F} SAE 80W-90
Capacity (L {US qt, lmp qt}) 2.87 {3.03, 2.53}
Item Specification
Transaxle type FN4A-EL
ATF Type ATF M-V
Line pressure
(kPa {kgf/cm
2
, psi})
D, S, L range
Idle 330470 {3.44.8, 4868}
Stall 1,1601,320 {11.812.5, 168191}
R position
Idle 490710 {5.07.2, 71102}
Stall 1,6001,820 {16.318.6, 232264}
Engine stall speed (rpm)
D, S, L range 2,0002,600
R position 2,0002,600
Time lag (s)
N → D 0.40.7
N → R 0.40.7
Transaxle range
(TR) switch
(ohm)
P position 4,0854,515
R position 1,4251,575
N position 713788
D range 371410
S range 190210
L range 8796
Transaxle Fluid temperature
(TFT) sensor
(kilohm)
ATF temperature: 20 °C {4 °F} 236324
ATF temperature: 0 °C {32 °F} 84.3110
ATF temperature: 20 °C {68 °F} 33.542.0
ATF temperature: 40 °C {104 °F} 14.717.9
ATF temperature: 60 °C {140 °F} 7.088.17
ATF temperature: 80 °C {176 °F} 3.614.15
ATF temperature: 100 °C {212 °F} 1.962.24
ATF temperature: 120 °C {248 °F} 1.131.28
ATF temperature: 130 °C {266 °F} 0.870.98
