TECHNICAL DATA
TD9
TD
Wheel and Tires
*
1
: Total weight exceeds 160 g {5.65 oz}.
*
2
: One balance weight: 60 g {2.12 oz} max. If the total weight exceeds 100 g {3.53 oz} on one side, rebalance
after moving the tire around on the rim. Do not use 3 or more balance weights.
End Of Sie
Item Specification
Standard tire and wheel
Wheel
Size 15 × 6JJ 16 × 7JJ 17 × 7JJ
Offset (mm {in}) 50 {1.97} 55 {2.17}
Pitch circle diameter (mm {in}) 114.3 {4.50}
Material Steel Aluminum alloy
Tire
Size 195/65R15 91V 205/55R16 91V 215/45R17 87W
Air pressure
(kPa {kgf/cm
2
, psi})
Front
Up to 4 persons 220 {2.2, 32}
Full load 240 {2.4, 35}
Rear
Up to 4 persons 220 {2.2, 32}
Full load 300 {3.1, 44} 270 {2.8, 39}
Remaining tread (mm {in}) 1.6 {0.06}
Wheel and
tire
Wheel and tire runout Radial direction 1.5 {0.06} max.
(mm {in}) Lateral direction 2.5 {0.10} max. 2.0 {0.08} max.
Wheel imbalance (g {oz})
Knock-type*
2
:
9 {0.32} max.
Adhesive-type*
1
:
13 {0.46} max.
Knock-type*
2
:
8 {0.28} max.
Adhesive-type*
1
:
11 {0.39} max.
Knock-type*
2
:
7 {0.25} max.
Temporary spare tire
Wheel
Size 15×4T
Offset (mm {in}) 40 {1.57}
Pitch circle diameter (mm {in}) 114.3 {4.50}
Material Steel
Tire
Size T115/70 D15
Air pressure
(kPa {kgf/cm
2
, psi})
420 {4.2, 60}
Wheel and
tire
Wheel and tire runout Radial direction 2.0 {0.08} max.
(mm {in}) Lateral direction 2.5 {0.10} max.
