ELECTRICAL SYSTEM
GI21
GI
Fuse
Replacement
• When replacing a fuse, be sure to replace it with
one of the same capacity. If a fuse fails again, the
circuit probably has a short and the wiring should
be inspected.
• Be sure the negative battery terminal is
disconnected before replacing a main fuse.
• When replacing a pullout fuse, use the fuse
puller.
Direction of View for Connector
Part-side connector
Direction of view is from the terminal side.
* : Part names are shown only when there are
multiple connector drawings.
YMU000WA1
YMU000WA
K
WGIWXX0100E
