AUTOMATIC TRANSAXLE
K17
K
13. Inspect the resistance between the terminals B
and C.
• If not as specified, readjust the TR switch.
(See K18 TRANSAXLE RANGE (TR)
SWITCH ADJUSTMENT.)
Resistance
750 ohms
14. Tighten the TR switch mounting bolts.
Tightening torque
811 N·m {82112 kgf·cm, 7197 in·lbf}
Caution
•
••
• Do not use an impact wrench. Hold the manual shaft lever when removing the manual shaft nut, or
the transaxle may be damaged.
15. Install the manual shaft lever and the washer.
16. Set the adjustable wrench as shown to hold the
manual shaft lever, and tighten the manual shaft
nut.
Tightening torque
3246 N·m {3.24.7 kgf·m, 2433 ft·lbf}
17. Install the clip to the SELECTOR CABLE as
shown in the figure.
18. Shift the selector lever to P position.
19. Turn the manual shaft lever to P position.
A6E5614W010
A6E5614W012
A6E5614W101
A6E5614W018
