P82
ON-BOARD DIAGNOSTIC (DYNAMIC STABILITY CONTROL)
Diagnostic procedure
STEP INSPECTION ACTION
1 INSPECT WHEEL-SPEED SENSOR CIRCUIT
FOR OPEN CIRCUIT
• Turn ignition key to OFF.
• Disconnect DSC HU/CM connector.
• Measure resistance between suspected
sensor terminals of DSC HU/CM connector
(harness side).
 RF wheel-speed sensor: MI
 LF wheel-speed sensor: FJ
 RR wheel-speed sensor: KH
 LR wheel-speed sensor: QN
• Is resistance within 1.31.7 kilohm?
Yes Go to next step.
No Go to Step 3.
