B28
ENGINE
No.1 Engine Mount Rubber Removal Note
1. Suspend the engine using the SSTs.
2. Remove the through bolt A on the No.1 engine
mount bracket side.
3. Loosen the through bolt B on the chassis side
until approximately three pitches are showing.
Note
• Do not remove the No.1 engine mount
rubber from the vehicle.
No.4 Engine Mount Bracket and No.4 Engine Mount Rubber Removal Note
1. Secure the engine and the transaxle using an
engine jack and attachment as shown.
AME2215W004
AME2213W002
AME2213W003
AME2218W001
To Next Page
