B30
ENGINE
2. Tighten the No.3 engine joint bracket bolt and nut
in the order shown.
No.4 Engine Mount Bracket and No.4 Engine Mount Rubber Installation Note
1. Tighten the No.4 engine mount bracket and No.4
engine mount rubber bolt and nut in the order as
shown.
2. Secure the engine and the transaxle using an
engine jack and attachment as shown.
3. Remove the hoist and secure the engine and
transaxle using SST.
AME2213W010
AME2213W011
AME2218W001
AME2215W004
To Next Page
