REAR SUSPENSION
R37
R
Caliper Component Removal Note
1. Suspend the caliper aside with cable.
Bolt (Trailing Link Front Side) Removal Note
1. Support the trailing link with a jack.
Caution
•
••
• Removing the trailing link is dangerous.
The trailing link could fall and cause
serious injury or death. Verify that the
jack securely supports the trailing link.
2. Remove the bolts (trailing link front side).
Bolt (Rear Lateral Link Outer Side) Removal Note
1. Loosen the bolt (lateral link inner side).
2. Remove the bolt (lateral link outer side).
Bolt (Trailing Link Front Side) Installation Note
1. Support the trailing link with a jack.
2. Tighten the bolts (trailing link front side).
End Of Sie
REAR CROSSMEMBER REMOVAL/INSTALLATION
A6E741628400W01
Caution
•
••
• Performing the following procedures without first removing the ABS wheel-speed sensor may
possibly cause an open circuit in the harness if it is pulled by mistake. Before performing the
following procedures, remove the ABS wheel-speed sensor (axle side) and fix it to an appropriate
place where the sensor will not be pulled by mistake while servicing the vehicle.
1. Remove the rear auto leveling sensor and harness.
(See T32 REAR AUTO LEVELING SENSOR REMOVAL/INSTALLATION.)
2. Remove the middle pipe.
(See F35 EXHAUST SYSTEM REMOVAL/INSTALLATION.)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Adjust the headlight zeroset.
(See T31 HEADLIGHT ZEROSET.)
6. Inspect the rear wheel alignment.
(See R6 REAR WHEEL ALIGNMENT.)
A6E7416W005
A6E7416W005
