Mazda 6 2002 - Page 716

R38
REAR SUSPENSION
.
A6E7416W020
1 ABS wheel-speed sensor
2 Parking brake cable
3 Caliper component
(See R39 Caliper Component Removal Note)
4Disc plate
5 Spindle and hub component
(See M10 WHEEL HUB, HUB SPINDLE
REMOVAL/INSTALLATION)
6 Bolt (stabilizer control link)
7 Rear coil spring
(See R29 REAR COIL SPRING REMOVAL/
INSTALLATION)
