T128
AIR BAG SYSTEM
2. Connect the SST (Adapter harness) to the driver-
side air bag module as shown in the figure.
3. Install the driver-side air bag module. (See T120
DRIVER-SIDE AIR BAG MODULE REMOVAL/
INSTALLATION.)
4. Connect the SST (Deployment tool) to the SST
(Adapter harness).
5. Connect the red clip of the SST (Deployment tool)
to the positive battery terminal and the black clip
to the negative battery terminal.
6. Verify that the red light on the SST (Deployment
tool) is illuminated.
7. Make sure all persons are standing at least 6 m
{20 ft} away from the vehicle.
8. Press the activation switch on the SST
(Deployment tool) to deploy the driver-side air
bag module.
9. Disconnect the SST (Deployment tool) from the
SST (Adapter harness).
10. Connect the SST (Deployment tool) to the SST
(Adapter harness).
11. Perform steps 5 through 8, in order to deploy the
driver-side air bag module.
Passenger-side air bag module
Warning
•
••
• Passenger-side air bag module is the dual inflator type. When the inflators are forced to be
deployed simultaneously, one of them may fail to deploy. When disposing the air bag module, the
inflators may be deployed accidentally. Make sure to deploy the inflators sequentially, following
the procedures below.
1. Remove the glove compartment.
2. Disconnect the passenger-side sir bag module connector.
3. Connect the SST (Adapter harness) to the
passenger-side air bag module as shown it the
figure.
A6E8130W011
A6E8130W050
A6E8130W028
A6E8130W014
