MULTIPLEX COMMUNICATION SYSTEM
T–3
T
OUTLINE
A6E811155430201
• A TCM and a 4WD control module have been adopted for the CAN system-related module.
End Of Sie
STRUCTRURAL VIEW
A6E811155430202
.
End Of Sie
MULTIPLEX COMMUNICATION SYSTEM
4
1
3
2
5
A6E81111101
1 ABS (ABS/TCS) HU/CM (with ABS (ABS/TCS))
DSC HU/CM (with DSC)
2 Instrument cluster
3TCM
4PCM
5 4WD control module
