BRAVO TWO GEAR HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3C-41
29. Bend one tab into retaining nut as shown after propeller shaft preload has been set
correctly. Bend remaining tabs down into gear housing. Cushion housing to avoid
chipping or scratching paint.
19831
a
b
c
a-Tab Washer Tab
b-Groove In Retainer
c-Cushioning
30. Install anodic plate. Torque screw to 20 lb-ft (27 Nm).
a
a-Screw
