OILDYNE TRIM PUMP SERVICE MANUAL NUMBER 28
Page 5A-48 90-863160 MAY 2000
6. Reinstall the spring and brush in the brush holder.
22638
b
a
c
a-Brush Holder
b-Spring
c-Brush
7. Position the brush hold down arms and tighten them securely. Do NOT overtighten.
22648
a
b
a
b
a-Brush Hold Down Arms
b-Screws
8. Position the brush wire as shown before reassembly.
22634
a
a-Brush Wire
