POWER STEERING SERVICE MANUAL NUMBER 28
Page 6A-24 90-863160 MAY 2000
4. Discard o-rings and retain the other parts.
22155
a
b
c
d
e
f
f
f
f
f
a-Fitting Assembly
b-Control Valve Assembly
c-Flow Control Spring
d-Studs
e-Reservoir
f-O-rings
5. Position retaining ring so that ring end is 1 in. (25 mm) from end of hole in housing.
6. Support housing in press and push down on end plate to remove tension on retaining
ring
7. Insert awl into hole in housing to push ring from recess.
8. Use a screwdriver to remove retaining ring and end plate.
22151
22152
a
b
c
a-Retaining Ring
b-Hole
c-End Plate
