© 2004 Microchip Technology Inc. DS70070B-page 23-13
Section 23. CAN
CAN Module
23
Register 23-15: CiRXFnEIDL: Acceptance Filter n Extended Identifier Low
Upper Byte:
R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x U-0 U-0
EID<5:0>
— —
bit 15 bit 8
Lower Byte:
U-0 U-0 U-0 U-0 U-0 U-0 U-0 U-0
— — — — — — — —
bit 7 bit 0
bit 15-10 EID<5:0>: Extended Identifier bits
bit 9-0 Unimplemented: Read as ‘0’
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
