Oce plotwave 345 User Manual

Disconnect the network cable and the mains supply cable
Procedure
IMPORTANT
Make sure the main power switch (A) is in 'off' position.
1.
Disconnect the network cable from the network connection at the right back of the printer (C).
A
B
C
2.
Disconnect the mains supply cable from the wall socket.
3.
Disconnect the other side of the mains supply cable from the power connection at the left back of
the printer (B).
Disconnect the network cable and the mains supply cable
Chapter 5 - Maintain the Printing System
215

Oce plotwave 345 Specifications

General

Resolution	600 x 1200 dpi
Memory	4 GB
Hard Drive	500 GB
Print Technology	Electrophotography LED
Print Speed	6 A1/D prints per minute
Media Handling	Rolls
Maximum Media Width	36 inches
Technology	Océ Radiant Fusing
Media Width	Up to 36 inches
Roll Capacity	Up to 2 rolls
Media Length	Up to 18.3 m (60 ft)
