Oce plotwave 345 User Manual

Connect the mains supply cable and the network cable
Procedure
IMPORTANT
Make sure the power switch (B) is in 'off' position.
1.
Plug the mains supply cable into the power connection at the left back of the printer (A).
A
B
C
2.
Plug the other side of the mains supply cable into the wall socket.
3.
Plug the network cable into the upper (RJ45) connection port at the right back of the printer (C), to
connect the printer to your company network.
Connect the mains supply cable and the network cable
222
Chapter 5 - Maintain the Printing System

Oce plotwave 345 Specifications

General

Resolution	600 x 1200 dpi
Memory	4 GB
Hard Drive	500 GB
Print Technology	Electrophotography LED
Print Speed	6 A1/D prints per minute
Media Handling	Rolls
Maximum Media Width	36 inches
Technology	Océ Radiant Fusing
Media Width	Up to 36 inches
Roll Capacity	Up to 2 rolls
Media Length	Up to 18.3 m (60 ft)
