Oce plotwave 345 User Manual

Clear a media jam in the roll feed section
Introduction
If a media jam occurs in the roll feed section, follow the help wizard on the user panel and take
the following steps:
Procedure
1.
Firmly pull the media drawer to open it.
2.
Remove any jammed printing material from the paper path and, if necessary, pull back the media
and rewind it.
3.
Reload the media roll if necessary and press the [clean cut button] to trim a strip of the media roll.
4.
Close the media drawer.
Clear a media jam in the roll feed section
272
Chapter 8 - Solve Problems

Oce plotwave 345 Specifications

General

Resolution	600 x 1200 dpi
Memory	4 GB
Hard Drive	500 GB
Print Technology	Electrophotography LED
Print Speed	6 A1/D prints per minute
Media Handling	Rolls
Maximum Media Width	36 inches
Technology	Océ Radiant Fusing
Media Width	Up to 36 inches
Roll Capacity	Up to 2 rolls
Media Length	Up to 18.3 m (60 ft)
