Oce plotwave 345 User Manual

The components of the printer (back)
3
1
2
Component - function table
No. Component Description / Function
1 [power switch] Switch the main power supply on or off.
You can find the serial number of the printer on
the sticker above the power switch.
2 [upper back cover] Open the [upper back cover] with the [media jam
clearance handle], when you want to access the
heater section in case of a media jam.
3 [media jam clearance handle] Use this handle to access the paper in case of a
paper jam in the heater section.
The components of the printer (back)
24
Chapter 2 - Get to Know the Printing System

Oce plotwave 345 Specifications

General

Resolution	600 x 1200 dpi
Memory	4 GB
Hard Drive	500 GB
Print Technology	Electrophotography LED
Print Speed	6 A1/D prints per minute
Media Handling	Rolls
Maximum Media Width	36 inches
Technology	Océ Radiant Fusing
Media Width	Up to 36 inches
Roll Capacity	Up to 2 rolls
Media Length	Up to 18.3 m (60 ft)
