The components of the scanner (optional)
NOTE
The scanner calibration sheet for the [Océ Scanner Express] is located in the media drawer, at
the back of roll 2.
The components of the scanner (top cover closed)
1
4
3
2
5
Component Description/Function
1 [top cover] Closes off the scanner.
2 [original feeding table] Use the [original feeding table] to feed the origi-
nal into the scanner (face up).
3 [open levers] Use the [open levers] to open the top cover.
4 [originals exit] Exit for the scanned original.
5 [output refeed protector] Prevents that your output is refed into the scan-
ner.
The components of the scanner (optional)
