8.5 RUN Mode Image Settings
You can set the type of an image displayed in the image display area and select whether or not to display other
items in RUN Mode. The type and color of a display image can be temporarily switched by pressing the B key in
SETUP mode. Once you switch from SETUP mode to RUN mode, the image of the type and color that you have
selected here is displayed.
The items settable with the use of RUN Mode Image Settings
Item Option Description
Display Camera Image Live-C1
Live-C2
Live-C1+C2
Memory-C1
Memory-C2
Memory-C1+C2
To switch the display images (the type of an image)
• By which camera the image was captured?
• Live image or memory image?
* C1: Camera 1
* C2: Camera 2
Display Gray Value
/Binary
Gray Value
/ Binary Groups A - H
The specified image is displayed in RUN mode.
• Gray Value
• Binary Groups A - H:
A binary image is displayed at the specified slice level.
Checker Shape On/Off To select whether or not to display a area frame of an checker in
RUN mode
Marker On/Off To select whether or not to display a marker in RUN mode
Ref. Point On/Off To select whether or not to display a line of reference
coordinates in RUN mode
Data Monitor On/Off To select whether or not to display the Data Monitor table in
RUN mode
Alignment of Data
Monitor
Default/ Right /Right
Top/Left
Bottom/Left/Left
Top/Up/Left Top
/Center
To select the display position of the Data Monitor table
Number of rows 1 – 10 To select the number of rows in the Data Monitor table
Number of columns 1 – 5 To select the number of columns in the Data Monitor table
