RS-232C Communication
11.3 Computer Link
11.3.1 Overview and Communication Specifications
Computer Link is the mode for the communications between a MICRO-IMAGECHECKER and a programmable
controller (PLC). The following communications are available for particular PLCs.
Data Output
The PV310 writes the inspection results and data to the specified register of PLC as the beginning. Therefore, the
PLC does not need a communication program to receive data.
Product Type Switch (PV310 Ver.1.1 or later)
At the timing of input the TYPE signal, PV310 refers to the value that has been stored in specified register of PLC
and switches the product type to the reference number.
When inputting a TYPE signal to switch the type, you can select the value in the register of PLC as described above
or the value specified by the parallel I/O input.
Communication Specifications
Item Specification
Communication Method Full duplex
Synchronous Method Asynchronous
Transmission Speed 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200-bit/s (Initial value: 9600)
Transmission Code ASCII
Bit Length 7-bit, 8-bit (Initial value: 8-bit)
Stop Bit 1-bit, 2-bit (Initial value: 1-bit)
Parity None, Odd, Even (Initial value: Odd)
Flow Control None, Software (Initial value: None)
Transmission
Format
Delimiter CR
Communication specifications can be configured by ENVIRONMENT > Serial Communication > RS232C. The setting
values of communication specifications must be the same as the PLC to communicate.
Available PLCs for Computer Link
Manufacture Model (series) name Available device Device No.
Panasonic Electric Works Co.,
Ltd.
FP series DT
0 - 9999
Mitsubishi Electric Corporation A series, Q series
(Support the special protocol for
MELSEC A-series computer link unit,
"Format 4")
D
FX series
OMRON Corporation C series, CV series, CS1 series D / DM
Allen-Bradley SLC500 N7
Fuji Electric FA Components &
Systems Co., Ltd.
MICREX-SX SPH series %MW3
