7.2 Numeric Calculation (CA01 to CA99)
7.2.1 Main Functions
Performing Calculations
This is a function to perform four arithmetic operations, trigonometrical functions. Up to 99 numeric calculations
can be set for each product type. See "Numeric Calculation and Input/Output Unit" for more information
Judging the Calculation Results
The numeric calculations are judged according to the acceptable range for OK judgment that you have set. If the
results of the numeric calculations are within the range, it is judged as “OK; otherwise, “NG”. The upper limit of
the range is called “Max.” and the lower limit of the range “Min.”.
Preparing for Outputting Data to the External Device
If you want to output the measured data to the external device, “Yes” must be displayed in the cell in the OUTPUT
column for each numeric calculation.
7.2.2 Reference Data and Calculation Functions
A List of the Data Can Be Referred to Numeric Calculation
The following reference data can be incorporated into Numeric Calculation formulas. After performing
calculations, the formulas including the symbols and numbers from 0 to 9 in the table below are displayed.
Reference Data Symbol Checker
No.
Object
No.
Refer.
No.
Reference Data Output Multiple
value
(*1
1 X Adjustment Amount 10-fold
2 Y Adjustment Amount 10-fold
0
3 Theta Adjustment
Amount
10-fold
4 X Coordinate 10-fold
5 Y Coordinate 10-fold
6 Proj. X Axis 10-fold
Position
Adjustment /
Rotation
Adjustment
PA 01 – 99
1 – 2
7 Proj. Y Axis 10-fold
Binary Window BW 01 – 99 - - Area
Gray Window GW 01 – 99 - - Average
1 X Coordinate 10-fold
2 Y Coordinate 10-fold
3 Proj. X Axis 10-fold
Binary Edge BE 01 – 99 -
4 Proj. Y Axis 10-fold
01 0 Det. Count
1 X Coordinate 10-fold
2 Y Coordinate 10-fold
3 Proj. X Axis 10-fold
Checker
Gray Edge GE 01 – 99
01 –
99
4 Proj. Y Axis 10-fold
