Panasonic Micro-Imagechecker PV310 - Ultra Compact Camera

25
Installation and Wirin
g
Cha
p
ter 2
2.4.2 Ultra Compact Camera
Mount a camera confirming the appropriate distance between the camera and the object (‘WD" in the below
table) and the gap (between the lens securing ring and the camera) for the required capture range (view range).
View Range Table - Ultra compact camera: ANPVCA1012
Lens
View range
(mm)
ANPVL3001
f=30 mm
ANPVL1201
f=12 mm
ANPVL0401
f=4 mm
Resolution
µm/pixel
Ver. Hor. WD Gap
Adapte
r ring
WD Gap
Adapter
ring
WD Gap
Adapte
r ring
Ver. Hor.
1 1.1 2.1 2.1
2 2.1 15 0.7 20 4.2 4.2
3 3.2 50 1 35 6.3 6.2
4 4.3 22 0 10 8.3 8.3
5 5.3 67 1.8 20 10 10
7.5 8.0 34 0 5 16 16
10 10.7 109 1.2 10 9 1.8 --- 21 21
12.5 13.3 12 1.5 --- 26 26
15 16.0 14 1.3 --- 31 31
20 21.3 193 0.6 5
*1
20 1.1 --- 42 42
30 32.0 110 1.8 --- 31 0.9 --- 63 62
40 42.7 144 1.5 --- 43 0.8 --- 83 83
50 53.4 178 1.3 --- 54 0.7 --- 104 104
75 80.1 658 1.9 --- 262 1.0 --- 82 0.6 --- 156 156
100 106.8 869 1.6 --- 346 0.8 --- 110 0.5 --- 208 208
150 160.2 1291 1.2 --- 515 0.7 --- 167 0.5 --- 313 313
200 213.6 1714 1.0 --- 684 0.6 --- 223 0.5 --- 417 417
250 267.0 2136 0.9 --- 853 0.6 --- 279 0.5 --- 521 521
300 320.4 2558 0.9 --- 1022 0.5 --- 335 0.4 --- 625 625
350 373.8 2981 0.8 --- 1191 0.5 --- 392 0.4 --- 729 729
400 427.2 3403 0.8 --- 1360 0.5 --- 448 0.4 --- 833 833
450 480.6 3825 0.7 --- 1529 0.5 --- 504 0.4 --- 938 938
500 534.0 4247 0.7 --- 1698 0.5 --- 561 0.4 --- 1042 1042
WD: The distance from the front of the lens to the object
*1 Replace the lens securing ring to use.
Fixing a Lens
1. Rotate a lens securing ring and fix it at the
appropriate position.
